• High performance and cost effective
• Data communication by SMS/GPRS (UDP/TCP)
• External GPS antenna tamper alarm
• GPRS roaming preference settings
• Tracking (by time interval, distance interval or smart mode)
• Logging up to 250,000 waypoints
• Geo-fencing event (circular)
• 10 Self-defined events
• Configurable power management
• RS232 interface forsupporting various applications i.e. Fuel level sensor, RFID reader, Barcode, or Camera ,etc.
• Speeding alert, Towing alerts, Power Low/Lost alert, Harsh Braking alert, Harsh Acceleration alert
• Firmware upgrading over the FTP server (FOTA)
• Built-in buzzer
• (QDI) Quick Develop Interface
• Support 1-Wire interface temperature function and i-Button driver ID
• Low power consumption
• LED indicator: GPS/Comm./RFID

Optional Features

• 1-Wire temperature sensor
• Built-in RFID reader (NFC)
• TPMS (Tire Pressure Monitoring System)
• Bluetooth BLE 4.0
• Camera
• 2.4 GHz RF TAG
• BLE fuel sensor
• BLE temperature sensor
• Breathalyzer
• I/O expansion board
• Support Mobileye 6 series CANBUS interface

• Dimensions (L x W x H):110mm x 68mm x 25mm  (w/o QDI board)
  Dimensions (L x W x H):110mm x 68mm x 34mm (w/ QDI board)
• Operating temperature: -20~+85℃ (without battery)
• Communication:

           - LTE bands: B1/B3/B7/B8/B28

           - WCDMA : B1/B8

           - GSM : 900/1800 MHz

• Support GPS/GLONASS GPS satellite system with high sensitivity antenna
• Triaxial acceleration sensor: ±16G.
• Built-in RFID reader (NFC) : support ISO15693 standard
• Power source: DC 8~32V
• Power consumption:

              -  45mA @ DC12V in Normal Mode

              - <3mA@ DC 12V in Sleep Mode

• Built-in 2 serial ports with 5V power supply  (including 1 DB9 connector)
• Memory capacity: 16 MB
• Positive input port: 2 digital input ports including 1 Analog input port
• Negative Input port: 1 digital input port or pulse counter
• Negative output port: 3 digital negative output port
• 1 Mini USB port
